OTW GNSS Module GPS GLONASS UART TTL for Motorcycle Systems

Place of Origin : China

Model Number : WT-62-UBL

Price : CN¥29.25/pieces 1-499 pieces

Type : GNSS Module

Country of Origin : Shenzhen Guangdong, China

Brand : OTW

Chipset : XX

Application : Positioning, surveying and mapping, etc

Operating mode : GPS+GLONASS

Output Mode : UART+TTL

Baud rate : 4800bps-921600bps,Default 9600bps

NMEA sentences : RMC,VTG,GGA,GSA,GSV,GLL

Update frequency : 1Hz-10Hz(default 1Hz)

Voltage : 1.8V to 3.6V

Power consumption : 17 mA @3.3V

Size : 12.2mm*16mm*2.4mm

Contact Now

WT-62-UBL GNSS Module for Motorcycle GPS Systems with GPS+GLONASS Support

Product Overview

High-performance GNSS module designed for motorcycle GPS systems, featuring dual GPS+GLONASS support for enhanced positioning accuracy and reliability.

OTW GNSS Module GPS GLONASS UART TTL for Motorcycle Systems

Key Specifications

Attribute	Value
Type	GNSS Module
Brand	OTW
Operating Mode	GPS+GLONASS
Output Mode	UART+TTL
Baud Rate	4800bps-921600bps (Default 9600bps)
Voltage	1.8V to 3.6V
Power Consumption	17 mA @3.3V
Dimensions	12.2mm × 16mm × 2.4mm

Technical Performance

Receiver Type	GPS/QZSS L1 C/A, GLONASS L1
Protocol	NMEA-0183 compliant or custom protocol
Channels	56
Sensitivity	Tracking: -162dBm, Capture: -160dBm, Cold start: -148dBm
Start Time	Cold start: 29s (avg), Hot start: 1s (avg)
Accuracy	Horizontal Position: <2.5m with SBAS
Update Frequency	1Hz-10Hz (default 1Hz)

Physical Characteristics

Interface: 24 pin stamp holes

Ports: 2 UART, 1 I2C, 2 SPI

Dimensions: 16.0mm × 12.2mm × 2.4mm (±0.5mm)

Power Specifications

Voltage Range: 1.8V-3.6V

Power Consumption: Operation: 17mA@3V, Power saving: 5mA@3V

Environmental Specifications

Operating Temperature: -40℃ to 85℃

Storage Temperature: -40℃ to 85℃

Humidity Range: 5% to 95% non-condensing

Product Tags:

GNSS module for motorcycles

GLONASS GPS GNSS Module

WT-62-UBL GNSS Module
